Product Introduction
This outdoor IP65-rated omnidirectional mobile signal jammer is engineered for rugged industrial and harsh-environment applications. Built with industrial-grade materials and a dual-sided heat dissipation system, it ensures uninterrupted operation under diverse weather conditions. The 360° high-gain omnidirectional antenna delivers full-coverage signal shielding with no blind spots. An integrated intelligent monitoring module provides real-time operational status and fault alerts, making it an ideal solution for prisons, gas stations, oil depots, inspection rooms, and secure conference facilities requiring stringent wireless signal control.
Product Feature
Industrial-grade protection: The enclosure meets IP65 protection standards, providing rain, dust, and corrosion resistance, making it suitable for long-term outdoor use.
High-reliability design: Utilizing efficient heat dissipation and power supply design, it supports 24/7 uninterrupted operation, meeting the continuous control requirements of critical locations.
Omnidirectional and efficient Jamming: Equipped with a high-gain omnidirectional antenna, it achieves 360° uniform radiation in the horizontal direction, effectively shielding mobile phone signals (2G/3G/4G/5G, Wi-Fi, and GPS bands) in specific areas.
Modular architecture: Each frequency band interference module adopts an independent board design, which supports on-demand configuration and quick replacement, facilitating daily maintenance and future frequency band expansion and upgrades.
Product Specificaiton
Effective Jamming: CDMA, GSM, SCDMA, DCS1800MHz, PCS1900MHz, PHS, GPS, WIFI,3G WCDMA, 4G LTE,5G,VHF,UHF ect, 2.4G & 5.8G wireless signal.
|
Channel |
Frequency |
Output power |
Antenna type |
|
|
CH1 |
758-803MHz |
30W |
Omni antenna |
|
|
CH2 |
869-894MHz |
30W |
Omni antenna |
|
|
CH3 |
925-960MHz |
30W |
Omni antenna |
|
|
CH4 |
1930-1990MHz |
30W |
Omni antenna |
|
|
CH5 |
2110-2170MHz |
30W |
Omni antenna |
|
|
CH6 |
2500-2690MHz |
30W |
Omni antenna |
|
|
CH7 |
3300-3600MHz |
30W |
Omni antenna |
|
|
CH8 |
3600-3800MHz |
30W |
Omni antenna |
|
|
CH9 |
2400-2500MHz |
30W |
Omni antenna |
|
|
CH10 |
5125-5350MHz |
30W |
Omni antenna |
|
|
CH11 |
5725-5850MHz |
30W |
Omni antenna |
|
|
CH12 |
1560-1610MHz |
30W |
Omni antenna |
|
|
CH13 |
1170-1390MHz |
30W |
Omni antenna |
|
|
Effective jamming range:Approximately 20-100 meters (Coverage range is significantly affected by factors such as distance to the base station, signal strength, building structure, and environmental obstructions.) |
||||
|
Host packaging: 54*64*44cm Gross weight: 33kg |
||||
|
Antenna packaging: 86*27*12cm Gross weight: 5.5kg |
||||
|
Power supply |
AC 110-220V, 50/60Hz or DC 24V/10A (optional) |
|||
|
Protection rating |
IP65 (completely dustproof and prevents water ingress). |
|||
|
Operating temperature |
-20°C ~ +60°C |
|||
|
Storage temperature |
-40°C ~ +80°C |
|||
|
Relative humidity |
10% ~ 80% (non-condensing) |
|||
|
Material |
Aluminum alloy die-cast casing, surface powder coated for corrosion protection. |
|||
|
Installation method: |
Wall-mounted or column-mounted (mounting bracket included) |
|||
Note: The specific shielding frequency band and power can be customized according to the operator network in the customer's country/region.
Application
Prison jammer, office signal jammer, Security jammer, indoor jammer, outdoor jammer, Military jammer, Conference room jammer, cctv jammer, cctv jammer. churche jammer, signal jammer, cell phone jammer, 5G cell phone jammers
