Product Introduction：
Backpack Ad Hoc Mesh Repeater self-organizing network radio: small size, light weight, equipped with high-capacity built-in battery, easy for single soldiers to carry, fully freeing their hands.
Ad Hoc Mesh Repeater Fast network access and automatic multi-hop relay can provide voice group calls, video return, relay transmission and other multimedia communication services for single soldiers, tactical teams, and tactical police dogs to achieve high-speed collaboration.
Beidou GPS positioning function, also supports wifi coverage, can cooperate with smart terminals with wifi function for various communications.
The system adopts the same frequency networking and multi-hop relay, and supports any network topology, such as point-to-point, point-to-multipoint, chain relay, mesh network and hybrid network topology.
It can provide wireless broadband communication for "peace and emergency" tasks such as emergency response, anti-terrorism and explosion prevention, covert investigation, special operations, disaster relief, daily patrol, etc.
Ad Hoc Mesh Repeater The transmission distance can reach more than 10km in open ground environment, 300~1000m in blocked environment (depending on the blocking environment), and more than 30km from air to ground.
Product Features
Anti-destruction: The failure of a single device will not affect the use of other devices in the entire
system.
Not dependent on base stations, efficiently and quickly form a decentralized wireless broadband network
Support TCP/IP/UDP network protocols, full IP networking, easy interconnection, compatible with IP based voice, data, and video services
Support multi-hop relay, which can effectively expand the coverage radius of wireless network
Support electromagnetic environment monitoring
Support remote parameter modification
Support one-click adjustment of bandwidth, frequency, power, mesh ID and other parameters
Support real-time channel monitoring, view spectrum signal strength, support monitoring device connection status through topology map
Support offline map, online map
Technical parameters
|
RF characteristics |
|
|
Working frequency: |
300MHz～5.8GHz (Frequency band can be customized) |
|
Working bandwidth |
5/10/20/40MHz |
|
RF Channel |
2T2R |
|
Transmit power |
2*5W |
|
Communication distance |
Single-hop transmission ≥5km (line-of-sight environment) |
|
Modulation |
QPSK,16QAM,64QAM |
|
Receiving sensitivity |
-103dBm@10MHz |
|
Network characteristics |
|
|
Maximum transmission bit rate |
95Mbps |
|
Network Protocol |
TCP/UDP |
|
Wireless Security |
Avoid illegal signal reception and mutual authentication between devices |
|
Number of nodes |
255 points |
|
Network access time |
Multi-point networking time ≤ 60s |
|
Relay hop count |
8 hops, the effective rate after 8 hops is not less than 4Mbps |
|
Network topology |
Centerless network, star network, chain network, mesh network |
|
Encryption |
AES128/256 |
|
Basic Features |
|
|
User Mode |
Supports handheld, backpack, and fixed-point control for front-end access |
|
Display |
2-inch touch screen, supports parameter setting, equipment status and signal display |
|
Interface |
SMA Port*2,RJ45*1,3.5mmHeadphone jack*1 |
|
WIFI |
Support 2.4G/5.8G |
|
Positioning module |
Support Beidou/GPS |
|
Voice intercom |
Support |
|
Work time |
Built-in battery, Contiuous working time ≥ 6H |
|
Charge port |
Type-C interface, supports fast charging, supports charging while using |
|
Other |
|
|
Dimension |
280mmx250.5mmx71mm(L*W*H) |
|
Net Weight |
1.0kg |
|
Work Environment |
Temperature -25℃～+55℃; relative humidity 90% |
|
Storage Enviroment |
Temperature -40℃～+85℃; relative humidity 90% |
