Handheld Drone Detector





Handheld Drone Detector AAT-HD-5T is a handheld device for detection, identification and direction finding of drones. It identifies drone flight control and image transmission signals based on spectrum sensing and artificial intelligence technologies. Its features include: direction finding for Drones; detection of drones with full frequency bands and various types; long detection distance and low false alarm rate; large color screen display with rich display content; small size, light weight, hand-held and It can cooperate with anti-interference guns, and is suitable for security tasks in major events, industrial parks, border and coastal defense and other places.





Product Feature

Handheld Drone Detector is Passive detection, no signal emission, no interference to the peripheral, environment friendly;

Extremely portable, works alone or couple with a counter drone gun;

Antennas of different frequency bands can be configured as required, and the antenna interface adopts a common standard, which is easy to disassemble and replace;

Type-C charging interface, can use common Android phone charger;

Drop proof, works well under extreme weather conditions;

Direction finding capability with the directional antenna.



Functions

Handheld Drone Detector is Real-time display of detailed drone information such as make, model, S/N, frequency, location (longitude, latitude, height) etc;

Handheld Drone Detector Supports adjustment of detection sensitivity in four levels;

Handheld Drone Detector Supports various alarm forms such as light, sound and sound and light, and the urgency of the alarm ringtone and the flashing frequency of the light are adjustable;

Direction finding capability after switching to the directional antenna;

Online update of drone library;

Low battery level alarm;

Multiple language optional;

Reset the device to out-of-factory state;

Storage and view of historical detection result data;

View of drone library, including drone make, model and frequency;

Signal strength display, the device can display the signal strength of the detected drone;

Detected drones that can invoke direction-finding function will be marked;

Once the device enters direction finding mode, the signal strength of the detected drone will be displayed, including maximum strength, instant strength and average strength.



Product Specificaiton

Performance

Omni-directional detection mode

Direction finding mode

#	Item	Technical Parameters
1	Operating mode	Passive detection
2	Drone models supported	DJI series drones,FPVs, Xiaomi, Yuneec, Hubsan, Hubson, Powervision, Tello drones etc.
3	Working frequency	2.4GHz,5.8GHz
4	Detection range	0-800 meters (urban environment, tested with DJI AIR2 as the target)
5	Azimuth	0°~360°(omnidirectional antenna)
6	Recognition time	≤2s
7	False alarm rate	≤once/day(In an anechoic chamber environment)
8	Swarm detection	≥10 concurrent drones

1	Operating mode	Directional passive detection
2	Action object	Some drones such as DJI (Phantom series and Yu series), Daotong and Hubson
3	Working frequency	2.4GHz and 5.8GHz
4	Detection distance	100-2000 meters (urban environment, tested with DJI AIR2 as the target)
5	Probe azimuth	≤±17.5°(Target 1km away with frequency locked)

Mechanical parameters

1	size	L*W*H：235mm*66mm*43mm(the host)
2	weight	≤800g(Antenna not included)
3	Battery life	≥6 hours
4	Charging time	≤3 hours (using the original charger)
5	Charging interface	Type-C

Electrical characteristics

1

Overall power consumption

≤6W

Environmental adaptability

1	Operating temperature	-20℃~55℃
2	Protection Lever	IP54

Battery parameters

1	Nominal capacity	5Ah
2	Nominal voltage	7.4V
3	Battery type	lithium battery
