A Multi Purpose Signal Measuring Equipment for Anti Eavesdropping
and Anti-Videotapping, Investigation and Evidence Collection
AAT- DT8-Plus is a professional handeld antiEavesdropping and Anti-Videotapping detectordevice. It can monitor and identify all wireless
videotaping equipment indoor or inside the car quickly and efficiently.No matter how those videotaping equipments camouflage themselves as something as clothes buttons, bags, tea cups,books, etc.), even if the device is hidden in the couch, on the ceiling and cement wall, they still can be located accurately
videotaping equipment indoor or inside the car quickly and efficiently.No matter how those videotaping equipments camouflage themselves as something as clothes buttons, bags, tea cups,books, etc.), even if the device is hidden in the couch, on the ceiling and cement wall, they still can be located accurately
AAT- DT8-Plus is Anti-Videotapping detector highly integrated with three working mode. All modes inter-change can be finished via a multi purpose switch. One mode is cell phone mode for detecting the cellphone signals only. Another model is wideband mode for detecting wireless signals range from 0-8000MHz. The other mode is Frequency Counter Mode for measuring the wireless signal range from 10-3000MHz. It can measure the frequency of all the digital and analog signals,such as mobile phone, wireless remote control, digital transmission station, car key, walky talky, 1.2G/2.4G wireless camera, wireless microphone, WIFI, WMAX and so on. It is easy to be operated. The equipment is designed LCD display
AAT- DT8-Plus Anti-Videotapping detector is with built-in lithium battery equipped with a smart charging system to make the battery working best. Designed with aircraft grade aluminum case to ensure high capability and durability of the equipment. All the completed set are packed in a military-grade suitcase,more protective and easier to be carried.
Feature
(1).8 bit LCD display
(2). Multi-functional navigation key operation and the function mode is optional
(3).This machine can measure the frequency of any digital and analog signal
(4).20 extrasensory synchronous RF signal strength indicator , sound and light vibrate silent alarm is optional
(5).Squelch adjustmen
(6).2 hour Low-power lithium battery
(7).High, medium and low battery LCD display
(8).LED charge status indicator
(9).Configured with full-band antenna and charging adapter
Frequency Counter Mode Specification:
Resolution: 10 KHz ( digital signal ) 1 KHz ( analog signal )
Impedance: 50 Ohms (MCX connector)
Frequency range: 10 MHz - 3 GHz
Sensitivity: -35 dBm Maximum Input: 15 dBm
Cellphone signal Mode Specification:
Impedance: 50 Ohms (MCX connector )
Frequency range: U.S. BANDS
LTE 700 CDMA 800 GSM1900 CDMA2000
LTE2300 WIFI 2400
EURASIAN BANDS
LTE 800 GSM900 GSM1800 WCDMA2000
LTE2600 WIFI 2400
Sensitivity: -60 dBm Maximum Input: 15 dBm
Broadband Wirless Signal Mode Specification:
Detection Frequency: 0-10GHz
Detection sensitivity: -65dBm
Audible alarm and mute function
Operation:
1. SQL Knob : Adjusting the received signal strength
2. Multi-functional navigation key: Press the button for 2 seconds to change the working mode , the test frequency range can be changed by up or down button in frequency meter mode multifunction key : 500MHz bandwidth can measure the range of 10 MHz to 0.5 GHz ; 3000 MHz bandwidth can measure the range of 500 MHz to 3 GHz; Right or left button can change the vibration , sound and light and mute warning display ; clicking multifunction key to keep count. Cell phone signal test mode function keys can change the sensitivity ( high, medium and low ) by up or down button . Right or left button can change the vibration , sound and light and
mute warning display. Wideband wireless signal test multi-function up or down button can change the sensitivity , there is 20 level can be selected, press the left and right direction can change the vibration, sound and light and mute warning display
Precautions:
1. Battery: digital frequency meter D8000-Plus is the use of rechargeable NiCd battery, on the premise of full battery , it can be used 3 hours;Please use the appendant charger when charging, the charging time is about 4 hours . In order to
preserve battery life, please take the battery recharged after the electric quantity running out , which can prevent the memory effect to extend battery life. For ease of use the recommendation is to use backup battery for replacement.
2. Signal input: In order to prevent damage to the machine, the singal input cannot be higher than the maximum frequency.When the frequency count installed the antenna, there may be some unknown frequency because the machine would get some of the weaker signals due to the large signal gain , once the signal reaches the normal standard of signal strength and frequency will be stable display .
3. Antenna selection: Full-band antenna can cover more bands , such as HF, VHF,UHF, CDMA, GSM, WCDMA, LTE, WIFI.
4.Test distance: Because there is a variety of RF signal from all around , resulting in the meter read the frequency value is not determined, the impact factors including :transmit power, signal strength, antenna matching , barrier or a different location under test may be affected.
